Exploring the tiny $9 C.H.I.P. computer

Lead Image © Denis Barbulat, 123RF.com

The Mouse that Roared

The C.H.I.P. is a cute little thing, but don't let appearances fool you: It is quite the beast deep down, and you can squeeze some seriously fun projects out of it.

At less than half the size and a third of the price of the Raspberry Pi (Rasp Pi), the tiny C.H.I.P. computer [1] packs quite a punch. C.H.I.P. comes equipped with a 1GHz Alwinner R8 processor. The C.H.I.P. board has had WiFi and Bluetooth support longer than the Rasp Pi. C.H.I.P. has 512MB of RAM and, instead of using an SD or a microSD card, it relies on 4GB of on-board flash memory to store the operating system and files, which means that the operating system and the firmware are one and the same. This design has its own set of consequences – some good, and some tricky.

On one hand, C.H.I.P. boots very quickly and is less prone to the operating system corruption that has plagued the Rasp Pi. On the other, you can't just download the operating system and copy it onto a memory card. Instead, you have to go through the slightly more complex (and scary) process of "flashing." But, don't worry, the creators of C.H.I.P. have developed a graphic tool that make the process much easier.

As for ports, the C.H.I.P. has one USB Micro B connector. That's the same kind of USB connector you'll find on your phone or to power the Rasp Pi. As with the Pi, you would usually use this port to provide power for the C.H.I.P. However, since you can also power the C.H.I.P. through the pin headers or a battery, you can use the USB port for different things. By default, connecting C.H.I.P.'s micro USB to a computer will create a USB Serial connection, so you can access C.H.I.P. with a screen or cu session in a terminal. With Linux kernel modifications, it is possible to enable the USB for other uses, such as an Ethernet bridge.

The other USB port is a Type A female connector, which is like the USB connectors you would typically find on the side of your laptop. This port is good for plugging a keyboard or mouse into the C.H.I.P. If you want to run a keyboard and a mouse together, invest in a powered USB hub.

The C.H.I.P. designers devised an interesting way of hooking the C.H.I.P. up to a display. It looks like a throwback to the 80s and the days of Commodore 64 and Sinclair Spectrum mini-computers. C.H.I.P. doesn't come with an HDMI or even a VGA connector. Instead, the C.H.I.P. has an 1/8" TRRS connector and a bright pink adapter (Figure 1). You plug one end into the TRRS (the TRRS is the circular port sandwiched between the USB ports and that looks like it's waiting for a headphone jack – in fact you can use it for a headphone jack), the other end goes into three female RCA on the back of your TV. On my TV, after trying several combinations (Figure 2), I got a video after selecting the TV's AV2 input.

Figure 1: The C.H.I.P. family photo. From left to right and top to bottom: the C.H.I.P., the Pocket C.H.I.P. console, a VGA adapter, an HDMI adapter, a spare battery, and the bright pink default TV adapter.
Figure 2: I felt like I was back in 1985, plugging a computer into the TV.

If you want a higher-quality image, you can also pay for a VGA or an HDMI adapter [2], but then you would also have to update the firmware. Another thing you can get for your C.H.I.P. is a battery, because your nine-dollar computer will happily run off one of those too.

Booting Up

Once you boot up, the interface should be immediately familiar. The C.H.I.P.'s default firmware is standard Debian (just like the Rasp Pi's) compiled for the Alwinner microprocessor. The default desktop is not LXDE like the Pi, but the very similar Xfce.

In the upper right corner of the screen, you'll see the icon that will allow you to access your WiFi network. Click on it, choose your network, input your password, and the C.H.I.P. will connect. (See the box entitled "Wifi Problems" if you have any issues with setting up wireless networking.)

WiFi Problems

While I was using the C.H.I.P., I noticed the WiFi would cut out from time to time. I also found it hard to access the C.H.I.P. from a desktop computer over SSH. We couldn't even get it to respond to ping commands. These problems might have been caused by the fact that WiFi power save management was switched on by default.

To correct this problem, first check to see what interface you are using:

ip addr

This command should reveal at least one interface up and connected to the network. Usually it is wlan0. To check and see if the power save feature is connected, run the following:

# iw dev wlan0 get power_save
Power save: on

If you get the on in the output, as shown above, you can disconnect the power save with:

iw dev wlan0 set power_save off

Then run iw dev wlan0 get power_save to make sure you have deactivated it.

Another common problem is the SSH server not starting properly. Check to ensure the SSH server is installed with:

sudo apt-get install openssh-server

APT will download, install, and run the server automatically. See if everything is working with:

systemctl status sshd

If there are no errors and the last line of output says something like

SOME DATE - SOME TIME chip server[SOME PID]: Server listening on :: port 22

you're good to go.

However, if you do get an error complaining about Could not load host key: ..., delete all the host keys with

sudo rm /etc/ssh/ssh_host_*

And regenerate them again with:

sudo ssh-keygen -A

Next, restart the SSH server:

sudo systemctl restart sshd

Now, if you check the status of the server, as shown above, everything should show up clean, and you should be able to connect from another computer on the network. You can connect using user chip and the default password chip.

Click on Computer Things! to open the application menu (Figure 3), and you will be able to access all the graphical software. You can use the Settings Manager to adjust your keyboard, the language, and the look and feel of your C.H.I.P.

Figure 3: Click on Computer Things! to access all the applications.

Apart from Xfce's configuration manager, a web browser, graphics programs, a terminal emulator, and so on, there are two great and original games you must try: Alex the Allegator 4 (that's not a typo, by the way, and I wonder what happened to 1 through 3), and Spout, an incredibly addictive 8-bit wonder. With the Thunar file manager (Figure 4), you will able to navigate through your folders and files – and even connect to servers using most network protocols.

Figure 4: Thunar is the default file browser. You can also use it to browse the network.

Eventually, you will want to install your own software. Reach the package installer, choose System, and pick the Package updater. You should run this from time to time, maybe daily, to make sure your system is fully up to date.

You have two available package tools: Packages and Synaptic. Theoretically, they both do the same thing. Synaptic (Figure 5), however, is a graphical software management system that Debian users have been using for years, and it seems more complete. Open Synaptic and first click on the Reload button to see the complete catalog of available packages.

Figure 5: Synaptic allows you to manage all your packages from one single app.

Of course, you can also install packages from the command line with:

apt-get update
apt-cache search <packagename>
apt-get install <packagename>

Flashing

Sooner or later, you will probably want to get your C.H.I.P. doing something else. Maybe you bought it with the Pocket console and you want to use it connected to a regular monitor and hook up a regular keyboard and mouse. Or maybe it's the other way round, you read this article, and it tempted you to splash out on the Pocket console, but your C.H.I.P. came configured as a regular computer.

Being a little beast, and the key word being little, the C.H.I.P. doesn't have much space for the firmware/operating system. This means that there are several firmwares around for each specific use you're going to give your micro-computer. With the Pi, you can just power down, switch to another SD/microSD card, and power up again. But, as mentioned above, the C.H.I.P. doesn't use an external card. Instead, the operating system is stored in a 4GB flash memory chip soldered onto the board. To get an operating system onto that, you're going to need to flash it.

Don't worry, because flashing the C.H.I.P. is quite easy. You will need to use the Chrome or Chromium web browser for this, since the tool requires a Chrome-specific extension.

Visit the C.H.I.P. Flasher site [3] to download and install the extension [4]. You will have the choice of a variety of firmwares (Figure 6). You can install the firmware on the fly, downloading and installing at the same time, or, if you click on the cloud icon in the upper right corner of each picture, you can download the firmware to your computer and then choose Flash from a file. The Flash from a file option is probably the safest.

Figure 6: The Flasher allows you to choose from a variety of firmwares.

The chrome extension will then guide you through the process (Figure 7):

Figure 7: The flashing process in order, from left to right and top to bottom.

1. The first screen is just a welcome screen. Press Next.

2. You will be asked to put the C.H.I.P. into FEL (flashing) mode. You put the system in flashing mode by connecting two pins: the FEL pin and a GND pin. Just in case it is not clear from the Flasher's animations, if you hold the C.H.I.P. with the USB ports towards you and facing upwards, the FEL pin is on the bank on the right, on the inner column, and fourth from the top (see Figure 8). You can use a jumper cable or an unfolded paper clip to connect to the GND pin at the bottom of the column. When you're done, press NEXT.

Figure 8: Connect the FEL pin to a GND pin to put the C.H.I.P. into flashing mode.

3. Use a USB cable to connect the micro USB on the C.H.I.P. to a USB port on your computer. The Flasher should detect the C.H.I.P. automatically. If it doesn't, make sure the USB port on your computer is not a USB 3 port (the ones with the blue "tongue" inside). If it is, try connecting the C.H.I.P. to a USB 2 port, since many users have reported problems with USB 3. If you don't have a USB 2 port on your computer, try using a USB hub with USB 2 ports connected to your computer.

4. If you have chosen to install from a pre-downloaded file (the recommended way), you will be asked to pick your file now.

5. Flashing then starts and doesn't need any intervention. Be very careful that the C.H.I.P. does not get disconnected from your computer, and make sure your computer is plugged into the mains. Otherwise, if the flashing gets interrupted for any reason, you could brick your C.H.I.P. [5]

6. After a while (between 20 minutes and half an hour in my experience), the flashing update will complete.
