Raspberry Pi IR remote

Lead Image © Letizia Giuffrida, 123RF.com

In Control

Turn a Raspberry Pi into an IR remote control for your DSLR, TV, or any other device with an IR port.

Connect an LED with a limiting resistor to Raspberry Pi's GPIO pins, and you can control the diode using code written in your preferred scripting language. However, if you can make the LED blink using the Raspberry Pi, couldn't you turn the little machine into an infrared (IR) remote control using an IR LED instead? It's possible, but it does require a handful of additional components and some work.

Although the idea of turning a Raspberry Pi into a glorified IR transmitter might sound like an interesting academic exercise, the final result can be used as a versatile replacement for a humble remote control. The most obvious advantage of using a Raspberry Pi-based IR remote control is that you can program it via scripts. You can also add some clever functionality on top. For example, you can write a simple server that makes it possible to access and control the Raspberry Pi-based IR transmitter from any machine or device.

Building and Testing an IR LED Circuit

Although you can connect an IR LED directly to GPIO pins on the Raspberry Pi, the LED's output signal will be too weak, and the IR transmitter will have a very limited range. A simple transistor circuit solves the problem by amplifying the current output from a pin and thus increasing the IR LED's signal strength.

To build a transistor-powered IR transmitter, you need two resistors (220ohm and 10K), a transistor (2N2222, BC547, or practically any other transistor will do), and a 940nm IR LED. Additionally, you'll need a breadboard and jump wires to assemble an IR transmitter prototype (Figure 1). Wire the components as shown in Figure 2 to assemble the IR transmitter. The next step is to check to see whether the IR transmitter actually works. To do this, you can use a simple LED Python blinking script (Listing 1) that turns the LED connected to pin 22 on and off.

Figure 1: Transistor-powered IR transmitter schematics.
Figure 2: Wiring diagram.

Listing 1

Python Blinking LED Script

01 #!/usr/bin/python
02 import RPi.GPIO as GPIO
03 import time
04 GPIO.setwarnings(False)
05 GPIO.setmode(GPIO.BCM)
06 GPIO.setup(22, GPIO.OUT)
07 while True:
08     GPIO.output(22, True)
09     time.sleep(1)
10     GPIO.output(22, False)
11     time.sleep(1)

Because the IR LED is not a regular light-emitting diode, how do you actually find out whether it blinks or not? You can use a camera with an LCD screen or smartphone camera. Point the camera at the circuit and look at the screen. If the circuit works, you should see the IR LED blinking.

Installing and Configuring the LIRC Package

To control a device with an IR receiver, the IR LED transmitter must send a specific signal sequence, and the LIRC package [1], which emulates the infrared signals of many remote controls, is the perfect tool for the job. LIRC is available in the Raspbian software repositories, so installing it on Raspberry Pi is just a matter of running

sudo apt-get install lirc

Once you've done that, you need to enable and configure the lirc_rpi kernel module. To do so, open modules in the Nano editor

sudo nano /etc/modules

and add the lines below to the file:

lirc_dev
lirc_rpi gpio_out_pin=22

Make sure that the gpio_out_pin parameter points to the pin controlling the IR LED (in this case, it's pin 22). Next, open the file /etc/lirc/hardware.conf in Nano as before with sudo and add the following configuration to the file:

LIRCD_ARGS="--uinput"
LOAD_MODULES=true
DRIVER="default"
DEVICE="/dev/lirc0"
MODULES="lirc_rpi"
LIRCD_CONF=""
LIRCMD_CONF=""

Now, reboot the Raspberry Pi using the

sudo reboot

command to activate the configuration. Finally, you need to specify a profile that emulates a specific remote control. The project's website [2] offers a long list of profiles that emulate practically any remote control in existence, including remote controls for DSLR cameras. So, if you want to use Raspberry Pi to control a Nikon D90 DSLR camera, point the browser to lirc.sourceforge.net/remotes/nikon/ML-L3 and copy the profile. Next, open the /etc/lirc/lircd.conf file in Nano, paste the copied profile into it, save the changes, and restart LIRC with:

sudo /etc/init.d/lirc restart

Turn on the DSLR camera and enable the IR triggering mode. On your Raspberry Pi, issue:

irsend SEND_ONCE Nikon2 shutter

If everything works properly, your camera should fire.
